Cam Motion Hotrod LS Performance Camshaft — 227° intake / 237° exhaust duration, .595″ intake / .587″ exhaust lift, 111° lobe separation angle with 4° advance

Description

Turn your LS swap into a street-strip animal with the Cam Motion Hotrod LS Camshaft (227/237 111+4). This hydraulic-roller grind delivers a lopey idle and strong mid-to-upper rpm power, and it works with cathedral or rectangle-port heads on 5.3–6.2L builds—EFI or carb.

Specs and recommendations straight from Cam Motion: .595″/.587″ lift with 1.7 rockers, 227/237° @ .050, 111 LSA on a 107 ICL. Ideal with headers, high-stall converter, and deeper gears.

Key specs

• Grind: XA227/350-XA237/345-11+4; SKU: 03-01-0075. Duration @ .050: 227/237 • Lift (1.7): .595″/.587″ • LSA/ICL: 111 / 107.

• Displacement range: 5.3–6.2L • Heads: Cathedral or rectangle port.

• Recommended combo: CR 9.4–10.5:1, 1-3/4″–1-7/8″ headers, 3000–4500 stall, 3.73–4.56 gears.

• Valvetrain notes: Cam Motion recommends .600″ beehive or .660″ dual springs and .080″ wall chromoly pushrods.

• Use case: Aggressive street / street-strip; great on stock short blocks and classic hot-rod LS swaps.
