Description
Holley Blue Fuel Pump With Regulator Kit Flows 110GPH Supports 550HP Rating, The motor draws only 3 amps and can be specified with up to 14 PSI maximum pressure. It comes complete with P/N 12-803 fuel pressure regulator. This pump is not compatible with alcohol or methanol fuels.
Street/Strip Carbureted Applications Gasoline Only
Features:
- 550HP Rating
- Tumble polished billet look
- Lower housing casting designed for enhanced fuel flow
- Motor draws only 3 amps current
- Relay kit P/N 12-753 & 7 1/2 amp fuse recommended
- Improved design for street/strip applications
- Not designed for use on aircraft of any type.
- Distinctive “Blue” logo
- Flows 110 GPH (free flow)
- Flows 88 GPH at 9 psi
- maximum pressure is 14 psi
- Includes P/N 12-803 fuel pressure regulator
- Provides constant fuel flow with no pulsation
- Has externally accessible pressure relief valve (max 14 psi)
- Rotor/vane pump design is more tolerant of contaminated fuels
- Weighs only 3 lbs
- Includes mounting bracket
- Repair kits are readily available
- Can be serviced from the pump end
- Not compatible with alcohol or methanol fuels
- Use of safety shut-off switch, P/N 12-810, strongly recommended
- Not designed or recommended for use with fuel injection systems
TECH RESOURCES
Fuel Pumps Technical Information
Instructions for Part# 12-802-1
Fuel Systems Selection Chart
Should be mounted below the fuel level of the tank for a good gravity feed on the inlet side. Relay kit P/N 12-753 recommended. These are to be used with 12 volt systems only.
