Description
This tank holds approximately 60 gallons of fuel. The float’s empty position in the S&B Tank is the same as the OEM tank. Since the bottom surface area on the S&B Tank is larger, the 60 Gallon tank with have a greater fuel reserve.
S&B Sump Fittings/Drain Plug fittings are required when using our sump feed/return port or after drilling out the bottom port to use as a drain. Fittings are under related products.
Do you have an Auxiliary Fuel Tank? Read why using these with our tanks will void the Lifetime Warranty.
| COMPATIBLE WITH GOOSENECK AND 5TH WHEEL | YES |
| COMPATIBLE WITH OE SKID PLATE | NO |
| DIMENSIONS | 79″ X 17.37″ X 19.37″ |
| DRAIN | YES |
| EMBEDDED FITTING THREAD SIZE | 1/2″ NPT |
| GROUND CLEARANCE COMPARE TO OE TANK | 2.9″ LOWER THAN STOCK. |
| OEM CAPACITY | 29 GALLONS |
| SENDING UNIT | OE |
| STRAPS INCLUDED | YES |
| SUMP | YES |
| S&B CAPACITY (APPROXIMATE) | 60 GALLONS |
| TANK TYPE | MIDSHIP |
| TRANSFER PUMP READY | YES |
| WEIGHT DRY | 45LBS |
