Description
The MSD 8-Plus Ignition Box produces the same extreme output of the original 8-Series, yet is now in a smaller housing with improved efficiency and internal components. One distinct change is now a built-in 2-Step Rev Control. Now you can switch between two rev limits without extra wiring or housings. For those that are looking for a dual fire MSD 8, the new 8-Plus is all you need. Our engineers were able to deliver an ignition that is capable of firing two coils at once for those extreme racers using dual plug race setups.
Features:
- Extreme spark output
- Built-in 2-step rev control
- Compatible for 4, 6 and 8-cylinders
- Single or dual coil output
Instructions for Part# 7805
| Brand | MSD |
|---|---|
| Current Draw | 36 Amps at 12,000 RPM |
| Emission Code | 4 |
| Features | Extreme Cylinder Pressure |
| Primary Voltage | 480 Volts |
| Product Type | Ignition Box |
| RPM Range | 15,000 RPM with 14.4 Volts |
| Secondary Voltage | 50,000 Volts Plus |
| Spark Energy | 315-345 mJ per spark |
| Spark Series Duration | 20 Degree Crankshaft Rotation |
| Voltage Required | 12-18 Volts, Negative Ground |
