Description
MSD Grid Controller Black Finish, The Power Grid Ignition System is the next evolution of our Programmable 7-Series Ignition Controls. The Grid incorporates an efficient 32 bit microcontroller and an all new software program, called MSD View, and is USB compatible. The Windows based software is designed with tabs to help racers easily select different programming windows and parameters.
- USB connection for ease of programming
- Timing based on engine rpm and gear value
- Advanced individual cylinder timing based on gear or time
- Five retard stages for nitrous
- Four steps of rpm limits for burnout, spool, launch and overrev
- Output switch set on rpm, pressure or time
- Shift light settings for each gear
- Ignition data acquisition accepts multiple runs
- Crank Trigger system highly recommended
Ignition Control Module – Power Grid Module – 5 Retard Stage Nitrous – Manual Launch Control – 4-Step Rev Limiter- Laptop Required- Each
| Brand | MSD |
|---|---|
| Current Draw | .5 – .7 Amps |
| Emission Code | 4 |
| Operating Voltage | 7-18 Volts |
| Product Type | Power Grid Controller |
TECH RESOURCES
Download MSD View Software
Pro-Mag Frequently Asked Questions
Instructions for Part# 77303
Addendum for Part# 77303
Power Grid 7720 Ignition Only Mounting Template
Power Grid 7730 Ignition Only Mounting Template
Power Grid 7740 Ignition Only Mounting Template
Power Grid Wiring Harness Detail
Power Grid Harness Adapter Detail
Power Grid To Pro-Mag Wiring Diagram
Power Grid To MSD 6A-L Wiring Diagram
Power Grid To MSD 8 Wiring Diagram
Power Grid To 7531 Wiring Diagram
Power Grid To MSD 7AL-3 Wiring Diagram
Power Grid To MSD 10 Wiring Diagram
Power Grid To 7AL-2 Wiring Diagram
Power Grid Single Accessory Can-Bus
Power Grid Dual Accessory Can-Bus
Power Grid Multi Accessory Can-Bus
Power Grid Overview: Basic Grid 101
Designed to be used with PN 7720 ignition controller. Can be used with MSD legacy ignition such as MSD 6, 7, 8 Series or a Pro Mag
